Engine:
Model: Komatsu SAA6D140E-5
Type: Water-cooled, 4-cycle, direct injection, diesel engine
Number of cylinders: 6
Displacement: 15.24 L (929 in³)
Gross power: 475 kW (637 hp) @ 1,800 rpm
Operating weight: 77,600 kg (171,096 lbs)
Bucket capacity: 4.5 - 13.0 m³ (5.9 - 17.0 yd³)
Maximum digging depth: 8.07 m (26 ft 6 in)
Maximum reach: 12.38 m (40 ft 7 in)
Swing speed: 6.3 rpm
Some additional specifications:
Hydraulic system:
Type: Variable displacement piston pumps and motors
Max. flow rate: 2100 L/min (554 US gal/min)
Relief valve pressure: 38.2 MPa (5,540 psi)
Undercarriage:
Track shoe width: 600 mm (24 in)
Track gauge: 3,800 mm (12 ft 6 in)
Ground pressure: 104.6 kPa (15.2 psi)
Dimensions:
Overall length: 13.59 m (44 ft 7 in)
Overall width: 4.65 m (15 ft 3 in)
Overall height: 5.12 m (16 ft 10 in)
