Engine:
Model: Komatsu S6D95L-1
Type: Water-cooled, 4-cycle, direct injection, diesel engine
Number of cylinders: 6
Displacement: 6.5 L (396.5 in³)
Gross power:
PC200-5: 92 kW (123 hp)
PC200-6: 107 kW (143 hp)
PC200-7: 110 kW (148 hp)
Hydraulic system:
Main pump type: Variable displacement piston pump
Maximum oil flow:
PC200-5: 2 x 132 L/min (2 x 34.9 US gpm)
PC200-6: 2 x 148 L/min (2 x 39.1 US gpm)
PC200-7: 2 x 166 L/min (2 x 43.9 US gpm)
Maximum pressure:
PC200-5: 34.3 MPa (4,975 psi)
PC200-6: 34.3 MPa (4,975 psi)
PC200-7: 35.0 MPa (5,076 psi)
Operating weight:
PC200-5: 19,100 kg (42,110 lbs)
PC200-6: 21,200 kg (46,750 lbs)
PC200-7: 20,900 kg (46,080 lbs)
Bucket capacity:
PC200-5: 0.8 - 1.2 m³ (1.0 - 1.6 yd³)
PC200-6: 0.8 - 1.3 m³ (1.0 - 1.7 yd³)
PC200-7: 0.8 - 1.4 m³ (1.0 - 1.8 yd³)
Maximum digging depth:
PC200-5: 6,710 mm (22 ft 0 in)
PC200-6: 6,950 mm (22 ft 10 in)
PC200-7: 7,025 mm (23 ft 0 in)
