Caterpillar 345C Hydraulic Excavator:
Engine: Caterpillar C13 ACERT
Gross power: 317 kW (425 hp)
Operating weight: 46,200 kg (101,851 lbs)
Bucket capacity: 1.5-5.5 m3 (2.0-7.2 yd3)
Maximum digging depth: 8.37 m (27 ft 6 in)
Maximum reach at ground level: 12.65 m (41 ft 6 in)
Maximum loading height: 7.79 m (25 ft 7 in)
Maximum travel speed: 5.3 km/h (3.3 mph)
Maximum gradeability: 70%
Dimensions (L x W x H): 11.52 m x 3.54 m x 4.14 m (37 ft 10 in x 11 ft 7 in x 13 ft 7 in)
Caterpillar 345C L Hydraulic Excavator:
Same specifications as 345C, except for:
Operating weight: 48,300 kg (106,260 lbs)
Dimensions (L x W x H): 11.94 m x 3.54 m x 4.14 m (39 ft 2 in x 11 ft 7 in x 13 ft 7 in)
Caterpillar 345C MH Material Handler:
Same specifications as 345C, except for:
Operating weight: 51,000 kg (112,436 lbs)
Maximum reach at ground level: 17.85 m (58 ft 6 in)
Maximum loading height: 14.85 m (48 ft 9 in)
Dimensions (L x W x H): 12.16 m x 3.68 m x 4.69 m (39 ft 11 in x 12 ft 1 in x 15 ft 5 in)
Caterpillar W345C MH Material Handler:
Same specifications as 345C MH, except for:
Undercarriage: wide gauge with 4 outriggers for added stability
Dimensions (L x W x H): 14.40 m x 4.98 m x 6.27 m (47 ft 3 in x 16 ft 4 in x 20 ft 7 in)
